Size Chart Guide

X
  • Below-Knee
  • Above-Knee
  • Measuring Tips & Videos

STEP 1: Bottom Circumference

Measure the circumference of your limb 4cm and 30cm up from the bottom. Continue to STEP 2: Find your size



Measuring for Willowwood Alpha Classic BK prosthetic liner.

STEP 2: Find your size

Take your top and bottom measurements and use the chart to determine your size. If you're in-between sizes, we suggest remeasuring again to be on the safe side. If the size you arrived at after measuring seems too big or small, in some cases it helps to use the size of your current liner as a very rough guide. The size may be printed on the liner or you can contact our team and provide the serial number printed on the side. Continue to STEP 3: Length

  BELOW KNEE   ABOVE KNEE
SIZE TOP BOTTOM   TOP BOTTOM
Small 20 - 27 cm 15 - 22 cm   - -
Medium 23 - 36 cm 18 - 26 cm   - -
Medium Plus 33 - 50 cm 20 - 28 cm   34 - 54 cm 20 - 32 cm
Large 36 - 55 cm 25 - 33 cm   37 - 64 cm 28 - 36 cm
Large Plus 40 - 60 cm 28 - 40 cm   44 - 80 cm 32 - 47 cm
X-Large 43 - 65 cm 33 - 45 cm   48 - 90 cm 37 - 55 cm

**Above Knee sizing is unavailable for Small and Medium

STEP 3: Length

Length is a matter of preference. You can trim this liner with a very sharp scissors. Start by applying your Willowwood Alpha Classic Prosthetic Liner and mark on the liner where you want to trim. Remove your liner and trim at your mark.



STEP 1: Bottom Circumference

Measure the circumference of your limb 4cm and 30cm up from the bottom. Continue to STEP 2: Find your size



Measuring for Willowwood Alpha Classic AK prosthetic liner.

STEP 2: Find your size

Take your top and bottom measurements and use the chart to determine your size. If you're in-between sizes, we suggest remeasuring again to be on the safe side. If the size you arrived at after measuring seems too big or small, in some cases it helps to use the size of your current liner as a very rough guide. The size may be printed on the liner or you can contact our team and provide the serial number printed on the side. Continue to STEP 3: Length

  BELOW KNEE   ABOVE KNEE
SIZE TOP BOTTOM   TOP BOTTOM
Small 20 - 27 cm 15 - 22 cm   - -
Medium 23 - 36 cm 18 - 26 cm   - -
Medium Plus 33 - 50 cm 20 - 28 cm   34 - 54 cm 20 - 32 cm
Large 36 - 55 cm 25 - 33 cm   37 - 64 cm 28 - 36 cm
Large Plus 40 - 60 cm 28 - 40 cm   44 - 80 cm 32 - 47 cm
X-Large 43 - 65 cm 33 - 45 cm   48 - 90 cm 37 - 55 cm

**Above Knee sizing is unavailable for Small and Medium

STEP 3: Length

Length is a matter of preference. You can trim this liner with a very sharp scissors. Start by applying your Willowwood Alpha Classic Prosthetic Liner and mark on the liner where you want to trim. Remove your liner and trim at your mark.



When measuring your thigh, pay special attention to how tight you take your measurement. It's best to pull the ends of your tape measure somewhat tight and then release. Your goal is to find a middle ground of how much tension you should apply to your measuring tape. Too tight and too loose will both result in a poorly fitting prosthetic liner.



FREE SHIPPING FOR USA ORDERS OVER $85

DONE

Prosthetic Categories

WillowWood

WillowWood Alpha Classic Liner, Cushion & Locking Liner, Low Activity, AK & BK, Classic Gel

WillowWood

WillowWood Alpha Classic Liner, Cushion & Locking Liner, Low Activity, AK & BK, Classic Gel

Size Chart Guide
$253.57 - $447.00
$253.57 - $447.00
Sale price
$19.99
Unit price
per

Free Shipping

*This product will delay your order 7-9 days.

X

Subscribing to Autoship? Great!

Image 1

Flexible frequency:

Not sure how often you need this product? No worries! You can always adjust it in your account.

Image 1

3 day reminder:

We'll email you a reminder before each shipment. If you're not ready, you can delay your delivery.

Cancel and modify anytime:

You can easily cancel, make changes, add products and manage your delivery schedule using your Amputee Store account.

Close

Buy all three

WillowWood Alpha Classic Prosthetic Liner Description

A comfortable socket and functional prosthesis often begins with your prosthetic liner. WillowWood released the Alpha Classic Liners to accommodate a wide variety of prosthesis users and applications. The Classic Gel is formulated with mineral oil gel to provide hydration for your skin, as well as allow gel to "flow" and adapt to uneven socket pressures.

The BK (below-knee) version is outfitted with WillowWood's durable Original Fabric that helps extend the life of your prosthetic liner. While the AK (above-knee) version is manufactured with their Max Fabric and provided abrasion resistant protection.

Benefits

  • Alpha Classic Gel Liner's mineral oil based formula hydrates your skin and contains Vitamin E
  • Available in both Below-Knee and Above-Knee sizing and styles
  • The Classic Gel formula allows for gel to flow between high and low pressure areas to offer a customized fit
  • Designed for low activity levels
  • Below-Knee style is 6mm uniform thickness in the front and 3mm along the back
  • Alpha Classic AK liner is 3mm thickness throughout the liner, except along the side and bottom area to help cushion the femur bone with 9mm of gel thickness
  • Alpha AK liner offers a dedicated shape for above knee prosthesis users
  • Abrasion resistant outer Max fabric on the Alpha AK Liner only
  • Latex free and hypoallergenic
  • Green/Grey color combination
  • Locking pin is not included
  • *Not vacuum approved as a replacement for the gel liner initially provided with your Vacuum System
  • Made in USA
  • Sold individually in a polybag

Suggested Use

The Alpha Classic Prosthetic Liner is available in both cushion and locking. And offers a unique AK version that offers added protection to the bottom end of the femur with 9mm of Classic Gel. If you replace your current liner please ensure your current liner is 6mm thick for below knee or 3mm thickness for above knee applications.

Below-knee version is offered in 6mm Uniform Gel thickness in the front and 3mm in the back.

Read our Prosthetic Liner Guide for more information on prosthetic liners.

How-to Apply

Invert your WillowWood liner so that the logo is on the inside. Place the end of your liner against the end of your limb. If using a pin lock liner, center the pin attachment on the bottom of your limb. Pay special attention when using the AK version to have the logo positioned along the outside. Carefully roll your liner onto your limb.

***Warning: Do not pull your liner onto your limb. Pulling the liner may stretch the skin and result in an uncomfortable fit and possible skin issues along the edge of your liner. Last, make sure that there are no wrinkles or air pockets between the liner and your limb. Air pockets cause excessive sweating.

Have product questions? We're here to help!

Chat

Features & Details

WillowWood Alpha Classic Prosthetic Liner Materials

Thermoplastic Elastomer (TPE) material enriched with Medical Grade Mineral Oil Gel

Directions for Use

Prior to applying your Alpha Classic Liner make sure your residual limb is clean, dry, and free of any soap residue. Cover any open wounds and non-intact skin with a product similar to Spenco. WillowWood states to avoid using any type of animal based lotions or powders on your residual limb or liner. These products may damage your WillowWood Liner.

Care Instructions

Proper hygiene is critical when wearing any prosthetic liner. Your Alpha Classic Liner must be thoroughly cleaned each day and disinfected once a week. Clean the gel side of your Classic liner using lukewarm water and a pH balanced prosthetic cleanser. Apply your prosthetic cleanser with a clean, soft cloth or sponge.

**Warning: Do not scrub your liner on either the fabric or gel sides.

Rinse your Alpha Gel Liner with water and dry it with a clean and lint-free cloth. Place your Classic Liner on a drying stand with the logo on the outside.

Once a week spray the gel side of your liner with ethyl alcohol spray and wipe clean with a lint-free soft cloth. Last, rinse any alcohol from your liner with water and dry again using the above instructions.

Precautions

Do not place your WillowWood Classic Liner on an open wound. If irritation, discomfort or poor circulation occurs, discontinue use and notify your physician or Prosthetist immediately. Do not wear an Alpha Classic for more than 20 hours daily.

This Alpha Classic Liner is not indicated for any amputee who has a skin condition which can be aggravated when covered by a non-porous gel material. The Alpha AK Liner should not be used by any prosthesis user whose residual limb is shorter than 3 inches, unless a secondary AK Belt is used.

Part Numbers (SKUs)

SIZE BELOW KNEE ABOVE KNEE
Small ALL-5063-E N/A
Medium ALL-5060-E N/A
Medium Plus ALL-5064-E AKL-2634-X
Large ALL-5066-E AKL-2636-X
Large Plus ALL-5068-E AKL-2638-X
X-Large ALL-5067-E AKL-2637-X

Returns

If you're not completely satisfied with your Amputee Store purchase, you can return your eligible items within 90 days of the original ship date. Items in new condition (unopened/unworn/unwashed) can be returned for a full product refund less original shipping costs. Please read our complete return policy for further instructions.
